Cupboard demo
Demo insights
Learn more about how this demo was set up and the DriveWorks technology it uses.
SOLIDWORKS® automation, BOMs, and cut lists
The cupboard demo shows how DriveWorks can automatically generate SOLIDWORKS drawings and related manufacturing documentation, including BOMs and cut lists frequently used in the furniture industry.
- A detailed BOM including all fixings is automatically created.
- Drawings are automatically created and exported as DXFs ready for use with CNC machining.
- Custom properties for material information are updated in all parts and drawings automatically.
Connect sales and manufacturing for streamlined selling
Input form validation and rule-based configuration ensures that only valid configurations can be submitted.
- Real-time pricing calculations update as the cupboard is configured. Currency options automatically update the price using currency multiplier rules and fulfilment costs.
- Images on forms ensure users can confidently select options and configure products quickly.
- Cover letter, quote, BOM, and cut list documents are updated in real-time as the cupboard is configured.
- Interactive 3D configuration uses appearances, scenes, lighting, and effects to accurately show the configured cupboard.
- The DriveWorks 3D preview extrude entity is used to create geometry for the panels of the cupboard, removing the need to load new geometry and maximizing performance.
